Yamaha 12-Channel Studio Audio DJ Sound Mixer – USB Audio Interface for Computer Recordin

Category:

Gadgets → Music & Sound Systems → Audio Mixers

Brand:

Yamaha

Recommended Model:

MG12XU — verify the physical model label before publishing

Product Type:

12-Channel Analog Mixing Console with USB Audio Interfaces

Yamaha 12-channel professional audio mixer with USB audio interface, microphone/line inputs, built-in SPX effects, +48V phantom power and computer connectivity for music recording, playback, live sound, DJ applications, church audio, studio production and events.

Product Description

The Yamaha MG12XU is a versatile 12-channel analog mixing console designed for live sound reinforcement, studio recording, DJ applications, worship services, conferences and other professional audio environments.

The mixer provides up to 6 microphone inputs and 12 line inputs, with D-PRE microphone preamps, 1-knob compressors, 2 AUX sends and built-in SPX digital effects. The XU version also provides a USB 2-in/2-out audio interface, allowing connection to a computer for digital audio recording and playback.

Its USB audio interface supports up to 24-bit/192 kHz operation, while +48V phantom power supports compatible condenser microphones.

Key Features

- 12-channel mixing console

- Up to 6 microphone inputs

- Up to 12 line inputs

- USB audio interface for computer recording and playback

- 24-bit / 192 kHz USB audio capability

- 2-in / 2-out USB audio

- Yamaha D-PRE microphone preamps

- +48V phantom power

- 1-knob compressors on applicable mono channels

- Built-in SPX digital effects

- 24 SPX effect programs

- 2 AUX sends including FX

- 2 GROUP buses

- XLR balanced stereo outputs

- Headphone and monitor outputs

- Metal chassis construction

- Suitable for studio and live sound applications

Technical Specifications

Specification| Details

Brand| Yamaha

Model| MG12XU

Mixer Type| Analog Mixing Console

Number of Channels| 12

Mono MIC/LINE Inputs| 4

Mono/Stereo MIC/LINE Inputs| 2

Stereo LINE Inputs| 2

Maximum Mic Inputs| 6

USB Audio| Yes

USB Configuration| 2-in / 2-out

USB Standard| USB Audio Class 2.0

Maximum Resolution| 24-bit / 192 kHz

Phantom Power| +48V

Digital Effects| SPX

SPX Programs| 24

AUX Sends| 2, including FX

Group Outputs| 2

Stereo Outputs| 2

Monitor Output| 1

Headphone Output| 1

Microphone Preamps| Yamaha D-PRE

Computer Connectivity| USB

DAW Compatibility| Compatible computer/DAW software

Dimensions| 308 × 118 × 422 mm

Net Weight| Approx. 4.2 kg

Construction| Metal chassis

Specifications above are based on Yamaha's official MG12XU documentation.

USB Computer Recording

Connect the mixer to a compatible computer through USB and select the Yamaha mixer as the audio interface in your recording software. Yamaha's documentation specifically supports using the MG12XU as a USB audio interface with a DAW.

This makes it suitable for:

- Music recording

- Podcast production

- Voice recording

- Live streaming

- YouTube production

- DJ recording

- Instrument recording

- Studio monitoring

- Computer audio playback

Ideal Applications

- Recording studios

- Churches and worship centres

- DJs

- Live bands

- Events and concerts

- Karaoke

- Podcast studios

- YouTube/content creation

- Conferences and seminars

- Schools and training centres

- Public-address systems

- Home music production

Package Contents

Typical package should include:

- 1 × Yamaha MG12XU mixer

- 1 × Power cable

- 1 × USB connection cable, where supplied

- Documentation/manual

Note: Software bundles and cables can vary by package, seller and market. Verify the actual package before listing accessories as included.

Frequently Asked Questions

Q: Is this a 12-channel mixer?

Yes. The MG12XU is a 12-channel mixing console with up to 6 microphone inputs and 12 line inputs.

Q: Can it record directly to a computer?

Yes. The MG12XU provides a 2-in/2-out USB audio interface for computer recording and playback.

Q: Does it support condenser microphones?

Yes. It provides +48V phantom power for compatible condenser microphones.

Q: Does it have built-in effects?

Yes. The MG12XU incorporates Yamaha SPX digital effects with 24 programs.

Q: Can it be used for DJ applications?

Yes. Its multiple line inputs, stereo outputs, monitoring facilities and USB connectivity make it suitable for DJ and live audio setups.

Q: Is it suitable for church sound systems?

Yes. The multiple microphone inputs, phantom power, effects, AUX sends and group outputs make it suitable for many church sound configurations.
